Lab 07: Remediation Workflows with Copilot Agents


Duration 45 minutes
Level Advanced
Prerequisites Lab 06, GitHub Copilot access

[!TIP] This lab covers GitHub-based remediation workflows. For the Azure DevOps pipeline variant, see Lab 07-ado: ADO YAML Pipelines.

Learning Objectives

By the end of this lab, you will be able to:

  • Review the A11yDetector agent and understand its scan-score-prioritize workflow
  • Invoke the detector agent on a demo app and interpret its output
  • Review the A11yResolver agent and understand its pattern-based fix approach
  • Apply remediation fixes proposed by the resolver agent
  • Create a remediation pull request with before/after evidence
  • Re-scan to verify the accessibility score improves after fixes

Exercises

Exercise 7.1: Review A11yDetector Agent

The scanner includes two Copilot agents that work together: a detector that identifies and prioritizes violations, and a resolver that proposes and applies fixes.

  1. Open .github/agents/a11y-detector.agent.md in your editor.

  2. Review the agent definition. The detector’s workflow:

    Step Action
    1 Scans the target URL using the scanner engine
    2 Calculates an accessibility score (0–100)
    3 Identifies the top 10 violations by severity and frequency
    4 Maps each violation to its WCAG 2.2 success criterion
    5 Produces a prioritized remediation report
    6 Hands off to the A11yResolver agent for fixes

  3. Note the handoff pattern — the detector invokes the resolver via Copilot’s agent system, passing the violation report as context. This separation allows each agent to specialize:

    • Detector: Expert in WCAG rules, scanning, and prioritization
    • Resolver: Expert in HTML/CSS/ARIA fix patterns

Exercise 7.2: Run Detection Scan

You will invoke the detector agent on demo app 001 to produce a prioritized violation report.

  1. Open GitHub Copilot Chat in VS Code (or your preferred Copilot interface).

  2. Invoke the detector agent:

    @a11y-detector Scan http://localhost:8001 and produce a prioritized violation report
  3. The detector runs the scan and returns a report that includes:
    • Overall score — The accessibility score for the page
    • Top 10 violations — Ranked by impact × frequency
    • WCAG mapping — Each violation linked to its success criterion
    • Remediation priority — Which violations to fix first for maximum score improvement

    Detector output report

  4. Review the prioritization. Violations are ranked by impact:
    • Critical violations (missing lang, keyboard traps) are highest priority
    • Serious violations (missing alt text, poor contrast) follow
    • Moderate and minor violations are lower priority

[!TIP] Fixing the top 3–5 critical/serious violations typically produces the largest score improvement. Focus on high-impact items first.

Exercise 7.3: Review A11yResolver Agent

You will examine the resolver agent that proposes code fixes for detected violations.

  1. Open .github/agents/a11y-resolver.agent.md in your editor.

  2. Review the resolver’s fix pattern table:

    Violation Fix Pattern
    Missing lang attribute Add lang="en" to the <html> element
    Missing alt text Add descriptive alt attributes to images
    Poor color contrast Update CSS colours to meet 4.5:1 ratio for normal text
    Missing form labels Add <label> elements associated via for/id
    Heading hierarchy Restructure headings to follow logical order (h1 → h2 → h3)
    Keyboard trap Remove or fix JavaScript that intercepts keyboard events
    Missing skip nav Add a skip navigation link as the first focusable element
    Ambiguous links Replace “click here” with descriptive link text
    Missing table headers Add <th> elements with scope attributes
    Deprecated elements Replace <marquee> and <font> with CSS

  3. The resolver references .github/instructions/a11y-remediation.instructions.md for detailed fix recipes. Each recipe includes before/after code examples and the WCAG criterion it addresses.

Exercise 7.4: Apply Remediation Fixes

You will use the resolver agent to propose and apply fixes to demo app 001.

  1. Invoke the resolver agent in Copilot Chat:

    @a11y-resolver Fix the top 5 violations in a11y-demo-app-001/static/index.html

  2. The resolver proposes targeted code changes. Review each proposed fix:

    • Add lang="en" to the <html> tag
    • Add <title> element with a descriptive page title
    • Add alt attributes to all <img> elements
    • Replace <div class="btn"> with <button> elements
    • Remove the keyboard trap JavaScript

    Resolver proposed fixes

  3. Accept the proposed fixes. The resolver modifies a11y-demo-app-001/static/index.html with the changes.

  4. Verify the fixes look correct by reviewing the diff in your editor.

Exercise 7.5: Create Remediation PR

You will commit the fixes and create a pull request documenting the before/after state.

  1. Create a feature branch for the remediation:

    git checkout -b fix/a11y-demo-001-top-violations

  2. Stage and commit the changes:

    git add a11y-demo-app-001/static/index.html
git commit -m "fix: remediate top 5 WCAG violations in demo app 001"

  3. Push the branch:

    git push -u origin fix/a11y-demo-001-top-violations

  4. Create a pull request:

    gh pr create \
  --title "fix: remediate top 5 WCAG violations in demo app 001" \
  --body "## Changes

Fixes the top 5 accessibility violations detected by the A11yDetector agent:

1. Added \`lang=\"en\"\` to \`<html>\` element (WCAG 3.1.1)
2. Added descriptive \`<title>\` element (WCAG 2.4.2)
3. Added \`alt\` attributes to all images (WCAG 1.1.1)
4. Replaced div buttons with semantic \`<button>\` elements (WCAG 4.1.2)
5. Removed keyboard trap JavaScript (WCAG 2.1.2)

## Before / After

| Metric | Before | After |
|--------|--------|-------|
| Score | ~25 | ~55 |
| Critical violations | 3 | 0 |
| Serious violations | 8 | 3 |
"

    Remediation pull request

Exercise 7.6: Verify Score Improvement

You will re-scan demo app 001 after applying fixes to confirm the accessibility score improved.

  1. Rebuild the demo app with the fixes:

    docker build -t a11y-demo-app-001 ./a11y-demo-app-001
docker stop a11y-001
docker rm a11y-001
docker run -d --name a11y-001 -p 8001:8080 a11y-demo-app-001

  2. Run the scanner against the updated app:

    npx ts-node src/cli/commands/scan.ts --url http://localhost:8001 --format json --output results/demo-001-after.json

  3. Compare the before and after results:

    $before = Get-Content results/demo-001.json | ConvertFrom-Json
$after = Get-Content results/demo-001-after.json | ConvertFrom-Json
Write-Host "Before: $($before.score)  After: $($after.score)"

    Before/after score comparison

  4. The score should show meaningful improvement. Fixing the top 5 violations typically raises the score by 20–30 points.

    Score improvement chart

[!TIP] To achieve a score above 90, additional fixes are needed beyond the top 5: improving colour contrast throughout, adding form labels, fixing heading hierarchy, and adding skip navigation. The A11yResolver agent can be invoked iteratively to address remaining violations.

Verification Checkpoint

Before completing the workshop, verify:

  • Reviewed the A11yDetector agent definition and understand its scan-score-prioritize workflow
  • Ran the detector and received a prioritized violation report
  • Reviewed the A11yResolver agent definition and its fix pattern table
  • Applied at least 3 remediation fixes to demo app 001
  • Created a pull request with before/after documentation
  • Re-scanned and confirmed the accessibility score improved

Congratulations

You have completed all 8 labs in the Accessibility Scan Workshop. Here is a summary of what you learned:

Lab What You Learned
Lab 00 Set up the development environment with Node.js, Docker, and scanner tools
Lab 01 Explored the 5 demo apps and mapped their violations to WCAG POUR principles
Lab 02 Ran axe-core scans via web UI, CLI, and API to detect WCAG violations
Lab 03 Used IBM Equal Access for broader policy-based scanning and compared with axe-core
Lab 04 Extended coverage with custom Playwright checks for issues automated engines miss
Lab 05 Generated SARIF output and uploaded findings to the GitHub Security tab
Lab 06 Built automated pipelines with matrix strategy, OIDC auth, and threshold gates
Lab 06-ado Configured ADO Advanced Security with SARIF integration (ADO track)
Lab 07 Used Copilot agents to detect, prioritize, and fix accessibility violations
Lab 07-ado Built ADO YAML pipelines for automated accessibility scanning (ADO track)

You now have the skills to implement a complete accessibility scanning platform that:

  • Scans web pages using multiple engines (axe-core, IBM Equal Access, custom Playwright checks)
  • Produces unified SARIF output for all scan engines
  • Integrates with GitHub Security tab or ADO Advanced Security for centralized alert management
  • Enforces accessibility gates in CI/CD pipelines with configurable thresholds
  • Automates remediation using AI-powered Copilot agents
  • Runs automatically on schedule and on-demand via GitHub Actions or ADO Pipelines
