Overview

Item Value
Duration 30 minutes
Level Intermediate
Prerequisites Lab 01 completed with a persisted .env

AI workloads are billed and throttled by tokens, not requests. notebooks/demo1-token-limits.ipynb applies the provider-agnostic llm-token-limit policy at API scope so one element enforces both a tokens-per-minute limit, returning 429 with Retry-After, and a daily token quota, returning 403.

A dedicated APIM subscription and an x-demo-run suffix in the policy counter key isolate this lab’s counters from other runs, other demonstrations, and any other traffic on the same instance.

[!NOTE] A backend 429 is not proof of the gateway limit. The demo1.rate_limit_429 objective passes only with gateway provenance, such as the remaining-tokens policy headers, and a quota 403 is never evidence of a content safety decision.

Learning Objectives

By the end of this lab, you will be able to:

  • Read an llm-token-limit policy and name the attribute behind each observed status
  • Interpret the tokens-consumed, remaining-tokens, and remaining-quota-tokens headers
  • Distinguish a gateway tokens-per-minute 429 from a backend throttle and from a quota 403
  • Reset every counter for the lab without waiting for a window to roll over
  • Explain how the session budget bounds the burst and accumulation loops

Exercises

Exercise 2.1: Read the policy

Get-Content policies/demo1-token-limit.xml

Expected result: one llm-token-limit element sets tokens-per-minute, token-quota, token-quota-period="Daily", estimate-prompt-tokens="false", and a counter-key that combines the subscription ID with the x-demo-run header.

The limit values come from named values rather than literals, and the backend authenticates with the APIM managed identity. The policy strips the client subscription key header and query parameter before forwarding, so the key never reaches the model backend.

Exercise 2.2 (Hands-on): Make a baseline call

Open notebooks/demo1-token-limits.ipynb and run the cells through the baseline call.

The baseline cell first sends unscored warm-up calls until the new API, subscription, and policy answer through the gateway. APIM applies new configuration asynchronously, so a fresh instance can return 404 or 401 for about a minute. The warm-up uses its own x-demo-run value, so the Demo 1 counters start clean.

Expected result: one 200 response with the three token headers present. This records the demo1.baseline objective.

With estimate-prompt-tokens="false", tokens-consumed reflects the prompt and completion usage the model reported.

Exercise 2.3 (Hands-on): Burst to a 429

Run the burst section.

Expected result: a bounded loop of rapid requests ends in a 429 with a Retry-After header, and the chart shows remaining-tokens falling across the burst. This records demo1.rate_limit_429 when the gateway headers confirm the source.

Exercise 2.4 (Hands-on): Accumulate to the daily 403

Run the accumulation section.

Expected result: the loop honors each Retry-After, remaining-quota-tokens decreases toward zero, and the gateway returns 403 once the daily quota is exhausted. This records demo1.quota_exhausted.

Both loops stop at a maximum iteration count and a wall-clock limit. In an automated session, every call also reserves input and maximum output tokens against the shared session envelope before it is sent, and a reservation that does not fit stops the loop with BudgetExceeded.

Exercise 2.5 (Hands-on): Reset the counters

Run the reset section.

Expected result: a new DEMO_RUN value is persisted to .env, and the follow-up call succeeds immediately. This records demo1.reset_recovery.

The resources stay in place because later labs reuse the same APIM instance.

Exercise 2.6: Review the session evidence

[!NOTE] Reviewed evidence from session 36608221120-1 (workflow run), rendered on 2026-09-29 from sanitized results only.

Objective results for Lab 02 from the reviewed session

Validation Checklist

  • The baseline response carried all three token headers
  • The 429 carried Retry-After and gateway provenance
  • The 403 appeared only after remaining-quota-tokens reached zero
  • A new DEMO_RUN value restored service immediately
  • All four Demo 1 objectives have a recorded status

Knowledge Check

  • Which llm-token-limit attribute produces the 429, and which produces the 403?
  • Why does a 429 from the model backend fail the demo1.rate_limit_429 objective?
  • How does changing DEMO_RUN reset the counters without touching the policy?
  • Why can APIM token limits overshoot under concurrent traffic?

Next Steps

Continue to Lab 03: Token metrics.
